The WA7DRE Yaesu Fusion Repeater is a Yaesu DR-1X repeater system complete with HRI-200 Wires-X Internet interface for linking to other Fusion nodes. The Internet interface computer is purpose built for years of trouble free operation. It contains no movings parts, spinning fans or rotating hard drives. It is 100% solid state.
Wires-X linking is working for analog and digital transmissions coming in from other nodes and rooms. Wires-X linking for digital only transmissions is still not available from Yaesu. All transmissions, whether from an analog or digital source, will be converted to a digital signal for output by the repeater. This is a digital input only Fusion repeater, analog input in FM mode is ignored.
|Primary Control Operator||Glen Ahlborn, K1RR|
|Output Frequency||443.525 Mhz|
|Input Frequency||448.525 Mhz|
|Analog/Digital Mode||Digital Only|
|TX Power||Medium (25W)|
|Antenna||Vertical colinear on 12' mast, 25' above ground|
|CTCSS (PL) Tone||None - Not Applicable|
|Tone Squelch Encoding||None|
|Wires-X Support||Full - HRI-200 Enabled|
|Wires-X Node Number||11375|
|Normally Connected to||#21375 [-WESTCOASTLINK-]|
|DTMF Tone for Disconnect||Use Wires-X features|
|DTMF Tone for Connect||Use Wires-X features|
Green = Handheld coverage, Yellow = Base or Mobile coverage
